Cambium C058940B132A ePMP Bridge in a Box 4518 5GHz US Cord
We’ll source it and quote it — usually within one business day.
Request a Quote →The Cambium ePMP Bridge in a Box 4518 is a pre-paired point-to-point kit of two 5 GHz Force 4518 radios, each with an 18 dBi integrated panel antenna, aimed at WISPs, integrators, and enterprises that want a turnkey wireless bridge. The two units arrive factory-configured to link to each other, removing the setup and pairing work of building a PtP hop from scratch. US power cord.
Mount one radio at each end, aim, and power up: the pair forms a bridge that carries a LAN across the gap between two buildings or towers. Both radios run on the ePMP 4500 platform, so the kit can later be re-tasked as subscriber modules on an ePMP 4500 sector, and the whole link is planned in LINKPlanner and managed in cnMaestro.
Key specifications
- Pre-paired kit of two Force 4518 radios for a complete PtP link
- 5 GHz wide-band operation, 5150 to 5920 MHz, configurable in 5 MHz increments
- 18 dBi integrated panel antenna on each radio
- 2x2 MIMO/OFDMA, interoperable with ePMP 4500 APs for MU-MIMO
- Selectable 20, 40, and 80 MHz channel widths
- Modulation up to 1024QAM
- 100/1000 BaseT Ethernet, Cambium and standard PoE pinouts
- Passive PoE input 27 to 59 V
- Operating temperature -30 to 55 C
Authorized, warrantied, and shipped warehouse-direct from Javelin Networks.
